高パフォーマンスの点火システム
Created with Pixso.

Boiler high-energy ignition system XDH hard soft rod high energy ignition rdevice

Boiler high-energy ignition system XDH hard soft rod high energy ignition rdevice

ブランド名: OEM
モデル番号: XDZ-1
MOQ: 1セット
支払条件: T/T
供給能力: 200
詳細情報
起源の場所:
中国
電圧:
2500V
エネルギー:
20J
スパーク周波数:
12〜14回/S
フレームサイズ:
300*200*120
糸:
M18*1.0 M18*1.5 M27*15
温度:
1300℃
ロッドディア:
Φ12、Φ16、Φ18
パッケージの詳細:
木製の箱の梱包
供給の能力:
200
ハイライト:

high energy ignition system

,

boiler ignition hard soft rod

,

XDH high performance ignition

製品説明
Boiler High-Energy Ignition System
XDH Hard & Soft Rod High Energy Ignition Device
Product Description
Portable high-performance ignition system heat box for XDH high-energy ignition device assembly. Compatible with DC 12V and AC 220V power inputs.
This ignition system utilizes ignition cable input voltage DC discharge to generate high-energy electric sparks through the forming head.
Technical Advantages
  • Low ignition voltage requirements
  • Excellent temperature resistance
  • Safety and reliability ensured
  • Strong pollution resistance capability
Applications
Designed for use as XDH high-energy ignition device assembly in industrial boiler systems.
Product Models & Series
Sr. Model Description
1 XDZ-1-l/d Standard type hard rod high energy ignition gun
2 XDZ-1-l/d B Standard type hard rod explosion-proof high-energy igniting gun
3 XDZ-1-l/d K Standard type hard gun handle high energy ignition gun
4 XDZ-1R-l/d Standard type soft rod high energy ignition gun
5 XDZ-1R-l/d B Standard type soft rod explosion-proof high-energy igniting gun
6 XDZ-2-l/d Non standard hard rod high energy ignition gun
7 XDZ-2-l/d B Non standard hard rod explosion-proof high-energy igniting gun
8 XDZ-2R-l/d Non standard soft rod high energy ignition gun
9 XDZ-2R-l/d B Non standard soft rod explosion-proof high-energy igniting gun
10 XDZ-3-l/d Special electric nozzle high-energy igniting gun
11 XDZ-3-l/d B Explosion proof special electric nozzle high-energy igniting gun
12 XDZ-4-l/d B The hard rod high clearance point guns
Note:
① In the table, code "l" represents igniting gun length in mm
② In the table, "d" represents igniting gun diameter with 14mm, 16mm, and 18mm series available
③ Custom designs and production available according to user requirements
Outline and Mounting Dimensions
Drawing 3-1: XDZ-1-l/18 Standard type hard rod high energy ignition gun (L≤1000mm)
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  0
Drawing 3-2: XDZ-1-l/18 Standard type hard rod high energy ignition gun (L>1000mm)
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  1
Drawing 3-3: XDZ-1-l/d B Standard type hard rod explosion-proof high-energy igniting gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  2
Drawing 3-4: XDZ-1-l/18 K Standard type hard gun handle high energy ignition gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  3
Drawing 3-5: XDZ-1R-l/18 Standard type soft rod high energy ignition gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  4
Drawing 3-6: XDZ-3 Catalytic plug ignition gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  5
Drawing 3-7: XDZ-4-l/d hard rod high pressure gap ignition gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  6
