Fluke 28II Ex Rugged Waterproof True RMS Multimeter with Intrinsic Safety Certification

Fluke 28II Ex Rugged Waterproof True RMS Multimeter with Intrinsic Safety Certification

ブランド名: Fluke
モデル番号: 28Ⅱ
MOQ: 1
価格: Negotistical
詳細情報
起源の場所:
OEM
直流電圧範囲:
0.1mVから1000V
パッケージの詳細:
新品オリジナルボックス
製品説明
Fluke 28II Ex Rugged Waterproof True RMS Multimeter with Intrinsic Safety Certification
The Fluke 28II Ex is a rugged, waterproof multimeter designed for demanding industrial environments with intrinsic safety certification for hazardous locations.
Accuracy Specifications

Accuracy specifications are displayed as ± (% of reading + digits)

Measurement Range Accuracy
DC Voltage: 0.1 mV to 1000 V ±(0.05% + 1)
AC Voltage: 0.1 mV to 1000 V ±(0.7% + 4)
DC Current: 0.1 μA to 10 A ±(0.2% + 4)
AC Current: 0.1 μA to 10 A ±(1% + 2)
Resistance: 0.1 Ω to 50 MΩ ±(0.2% + 1)
Conductance: 60.00 nS ±(1.0% + 10)
Diode Test: 2.0 V ±(2.0% + 1)
Duty Cycle: 0.0% to 99.9% Rise Time < 1 µs, within ±(0.2%/kHz + 0.1%)
Capacitance: 10 nF to 9,999 μF ±(1% + 2)
Frequency: 0.5 Hz to 199.99 kHz ±(0.005% + 1)
Temperature: -200°C to +1090°C (-328°F to +1994°F) ±(1% + 10)°C [±(1% + 10)°F]
Technical Features
  • Display Count: 6000/19999 counts in high-resolution mode
  • Peak Capture: Records transients up to 250 µs
  • Minimum/Maximum/Average Recording: Displays signals up to approximately 100 ms
Safety Certifications
  • ATEX {Ex} II 2G Ex ia IIC T4 Gb
  • {Ex} I M1 Ex ia I Ma
  • NEC-500 Class I, Zone 1, Groups A-D, 130°C
  • IECEx Ex ia IIC T4 Gb
  • Ex ia I Ma
  • GOST R Ex 1Ex ia IIC T4 Gb X
  • PO Ex ia I Ma X
  • IP6X
General Specifications
  • Power Supply: Three AAA Batteries
  • Battery Life: 400 Hours
  • Display: LCD with Backlight
  • External Protection: Rubber Case
  • Warranty: Three Years
  • Dimensions with Case (H x W x L): 6.4 x 10.0 x 19.8 cm (2.5 x 3.9 x 7.8 in)
  • Weight with Case: 700 g (1.54 lb)
